P25 ISSI CSSI Conformance (ICC Test Tool)

Valid8's P25 ISSI CSSI Protocol Conformance Test Suites provide a convenient method to test the dispatch console and the RFSS on the ISSI and CSSI interfaces according to the TIA and CAP standards.

Overview

P25 ISSI CSSI CAP Conformance Suites are an implementation of the P25 CAP ISSI/CSSI Conformance Test Tool (ICC Test Tool / ICCTT). The Valid8 Conformance Test Suites are suitable for testing many protocols and interfaces in the wireless and wireline network including S1AP, X2AP, F1AP, Diameter, HTTP2, PFCP, GTP, SIP, P25, ISUP, H.323 and many others. P25 CAP ISSI/CSSI Conformance Test Tool verification process.

What It Can Do For You

The Conformance solution is capable of simulating and testing several devices individually or in parallel.

It can simulate

  • RFSS
  • Console

It can test

  • RFSS
  • Console

Why It’s Different

  • Scalable software-based architecture can run on a range of hardware from COTS and high-end customer provided hardware to Virtual Machines and the Cloud (e.g. Amazon AWS) for maximum versatility and performance
  • Web-based UI is easy to learn
  • HTTP API enable integration with automation test systems and other equipment
  • Stateful modeling provides accurate emulation of network elements

Ordering INformation

P25 ISSI CSSI Conformance Tester

Conformance options:

sip-conformance-cap-suite : CAP conformance test suite

sip-conformance-tia-suite : TIA conformance test suite

Related Video

Features

  • Pre-made test scenarios and procedures
  • PASS / FAIL analysis, including plain English diagnostic reason
  • Valid / Invalid testing
  • Customizable scenario code
  • User-configurable proprietary messages, IEs, headers
  • Animated test results action-replay
  • Easy to configure
  • Automatic execution of test batches
  • UDP, TCP, SCTP transport layer IPv4/IPv6 support
  • Suitable for development and QA test lab environments, verifying protocol compliance, negative and robustness testing, Regression testing and reproducing customer issues in the field

Subsystems

KPIs
  • Verdict Pass/Fail/Inconclusive
  • Reason information
Configurable Parameters
  • DUT IP Address
  • DUT WACN ID
  • DUT System ID
  • DUT Group ID
  • DUT Unit ID
  • DUT Subscriber Unit
  • Valid8 Tester IP Address
  • Valid8 Tester WACN ID
  • Valid8 Tester System ID
  • Valid8 Tester RFSS ID
  • Valid8 Tester Group ID
  • Valid8 Tester Unit ID
  • Valid8 Tester Subscriber Unit

Automation API

User commands can be fully automated using REST API. This includes performing all test control functions as well as collecting results and metrics. It can be integrated into virtually any CI system via the HTTP API, including Jenkins, CircleCI, Gitlab and others.

Scripting

The application’s subsystems can be edited directly in the browser using TDL or by using the graphical tools. The Message Workshop allows for creating of test scenarios directly from the hex stream of a remote capture, while the Graphical Editor (on the feature roadmap for 3Q 2020) will allow for creating customized call scenarios by dragging and dropping the call flow to meet your test needs.

This is some text inside of a div block.

Use Cases

RFSS or Dispatch Console Under Test

For testing the RFSS or the dispatch Console, the Valid8 Tester can generate SIP PTT calls on ISSI or CSSI to test conformance to the published standards

Supported Scenarios:
  • Unconfirmed Group Call
  • Confirmed Group Call
  • Emergency Call
  • Emergency Alarm
  • REGISTER
  • INVITE SG calls
  • INVITE SU calls
  • PTT RTP IMBE/AMBE
P25 ISSI CSSI Conformance (ICC Test Tool)
P25 ISSI CSSI Conformance (ICC Test Tool)

Summary of Specifications

Specifications

Protocol Specifications

  • TIA-102.BACA-A, TIA-102.BACA-B TIA November 2012
  • TIA-102.BACA-B-1 TIA July 2013
  • TIA-102.BACA-B-1 TIA November 2016
  • TIA-102.BACD-A
  • TIA-102.BACD-B TIA July 2011
  • IETF RFC2327 - SDP
  • IETF RFC3261 - SIP
  • IETF RFC3550 - RTP / RTCP

TIA Conformance Test Suite

  • Test Specification: ISSI: TIA-102.CACC Jan 2009, P25-CAB-ISSI_TEST_REQ August 2016, CSSI: P25-CAB-CSSI_TEST_REQ Draft 2016
  • Number of tests included: 200

CAP Conformance Test Suite

  • Test Specification: P25-CAB-CSSI-CSS_CONF_TEST_CASES November 2018, P25-CAB-CSSI-RFSS_CONF_TEST_CASES November 2018, P25-CAB-ISSI-RFSS_CONF_TEST_CASES November 2018, P25-CAB-ISSI-CSSI_CONFORMANCE_TEST_REQ November 2018
  • Number of tests included: 130

Product Details

Operating System

  • ‍Protocol Engine (Linux-based)

User Interface

  • ‍Browser-based, touch-optimized graphical user interface

Automation

  • ‍HTTP API

Note:

Actual throughput levels over radio may vary based on the 3rd party device manufacturer and software versions. Valid8 product specifications are subject to change at any time without notice.

Valid8 exports its products strictly in accordance with all US Export Control laws and regulations which shall apply to any purchase or order. Specifications are subject to change without notice.
